The vertical settler for purification of conveyor and washing waters is used in sugar factories to separate tops, roots, solid impurities and suspended particles of earth from conveyor and washing water in order to reduce the amount of excess water with removed sediment.
You can flip through the table. (left / right)
| Characteristic | Ш1-П1700.РЭ |
|---|---|
| Sump productivity with 10% beet contamination: - on beets, t.w./day - for conveyor and washing water, m³/day | 1500 525 |
| Clarified water outlet, m³ | 440 |
| The output of a mixture of sediment and water, m³ | 85 |
| Sludge moisture content, % | 94 |
| Water velocity in the central pipe of the sump, mm/s | 30 |
| Overall dimensions, mm | 13586×11720×16810 |
